580m3/h desiccant type dehumidifier wholesale | pharmaceutical dehumidifier | East Dehumidifier OEM ODM Manufacturing
- Model
- SDC-600M
Item specifics
- Process Air Flow
- 580m3/h
- Dehumidity Type
- Desiccant
- Brand Name
- East Dehumidifier OEM ODM Manufacuring
- Location
- Zhejiang, China
- Condition
- Brand New
- Dehumidifying capacity(20°C,60%)
- 3kg/h
- Votage/Frequency
- 220V~230V/ 50Hz 60Hz
- Core Components
- Motor, wheels
- Function
- Air Dry
- Warranty
- 1 Year
Review
Description
EAST Desiccant Rotor Dehumidifier · Single Unit A compact single-unit desiccant dehumidifier that delivers 580 m³/h of deep-dried process air — ideal for pharmaceutical, laboratory and cold-storage rooms where stable low humidity matters. Every EAST single-unit desiccant dehumidifier combines a proven rotor core with intelligent control so you get steady low-humidity air without babysitting. A world-renowned desiccant rotor removes moisture continuously and is built to run trouble-free for more than 10 years. PTC elements regenerate the rotor with less energy, keeping power consumption low while drying performance stays high. The SCR system keeps internal temperature stable, so dehumidifying performance remains reliable even at low dew points. A precise control system with humidistat adjusts operation automatically to hold your target humidity level. Beyond removing moisture, this unit is designed to save you time, energy and maintenance over its service life. A single compact unit covers the environments that need dependable low humidity most. Maintains the stable low humidity that drug production and storage require, protecting product quality and consistency. Keeps refrigeration areas free of frost and condensation, working efficiently even at low temperatures. Holds precise humidity for sensitive instruments, samples and testing rooms where accuracy is non-negotiable. Protects stored goods from moisture damage and mildew all year round, reducing waste and rework. The SDC-600M column is highlighted below. Full series data is shown so you can size across the range. * Dehumidifying capacity measured at 20°C and 60% RH inlet condition. Specifications may be adjusted for customization projects. Each EAST unit is assembled and checked in our own factory, so what arrives on site is ready to run. As a desiccant rotor dehumidifier, the unit achieves far lower dew points than condensing units — suitable for low-humidity processes down to deep-drying conditions, with stable output verified at 20°C, 60% RH in the specification table above. Yes. Unlike refrigerant dehumidifiers, the desiccant rotor keeps working at low temperatures, which is why it is widely used in cold storage and outdoor-cold workshops. The applied temperature range is -10°C to +50°C. Absolutely. EAST Dehumidifier is an OEM/ODM manufacturer. We can customize airflow, regeneration options, voltage, control systems and packaging to match your market requirements. Tell us your airflow and target humidity — our engineers will recommend the right model and customization within one working day.
OEM / ODM Available
SDC-600M Desiccant Rotor Dehumidifier
Core Features Built for Reliable Deep Drying
Proflute Rotor Core
PTC Regeneration Heating
SCR Constant-Temperature Control
Intelligent Humidity Control
Advantages That Lower Your Operating Costs
Where the SDC-600M Delivers the Biggest Benefit
Pharmaceutical
Cold Storage
Laboratory
Storage & Warehouse
Technical Specifications — SDC Series
Model
SDC-300M
SDC-600M
SDC-700M
SDC-800M
SDC-1000M
SDC-1200M
SDC-1500M
SDC-2500M
SDC-3000M
Voltage / Frequency
220V/50Hz
220V/50Hz
220V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
Dehumidifying capacity (20°C,60%)
2.0kg/h
3.0kg/h
4.0kg/h
4.5kg/h
7.5kg/h
8.5kg/h
10kg/h
15kg/h
19kg/h
Power rating
2.0KW
4.5KW
7KW
10KW
11KW
13KW
15KW
24KW
27KW
Current
9A
20A
32.5A
16A
18A
20.5A
23A
37.5A
42A
Process air flow
320m3/h
580m3/h
700m3/h
850m3/h
1100m3/h
1250m3/h
1550m3/h
2500m3/h
3000m3/h
Reactivation air flow
110m3/h
200m3/h
220m3/h
260m3/h
400m3/h
450m3/h
580m3/h
925m3/h
1100m3/h
Process air flow pressure
80Pa
100Pa
120Pa
150Pa
150Pa
200Pa
200Pa
400Pa
400Pa
Reactivation air flow pressure
50Pa
70Pa
70Pa
100Pa
100Pa
150Pa
150Pa
200Pa
200Pa
Inlet size
Φ125mm*2
Φ125mm*2
Φ200mm*2
Φ200mm*2
Φ200mm*2
Φ250mm*2
Φ250mm*2
522*286/Φ400mm
522*286/Φ400mm
Outlet size
Φ80mm*2
Φ100mm*2
Φ125mm*2
Φ150mm*2
Φ150mm*2
Φ160mm*2
Φ160mm*2
Φ200mm*2
Φ200mm*2
Applied Temperature
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
-10~+50℃
Dimension
680*425*400mm
585*420*866mm
1080*550*671mm
875*640*1232mm
875*640*1232mm
880*678*1238mm
880*678*1238mm
1312*856*1300mm
1312*856*1300mm
Packed Dimension
780*525*550mm
685*520*1016mm
1280*650*821mm
975*740*1382mm
975*740*1382mm
980*778*1388mm
980*778*1388mm
1412*956*1500mm
1412*956*1500mm
Net Weight
45 kg
70 kg
100 kg
150 kg
160 kg
175kg
180 kg
270 kg
280 kg
Gross Weight
55 kg
80 kg
110kg
160 kg
170 kg
190 kg
195 kg
290 kg
290 kg
Tested and Verified Before Dispatch
Learn About Our Factory
Frequently Asked Questions
What dew point can the SDC-600M reach?
Can it operate in cold environments?
Do you support OEM / ODM customization?
Ready to Dry Your Process Air?
